ProtectoAutoclenz Twin Arm
PART NUMBER: EXT3AUT4415T
PART NUMBER:
EXT3AUT4415T
Register to Start OrderingSend Enquiry

ProtectoAutoclenz Wall Twin unit is a self cleaning wall mounted welding fume filter incorporating a separator, two durable large surface area filter cartridges, and complete with a filter monitor, post-cleaning function and hour meter. The unit is capable of handling up to 3500 m³/hr and is available with 2x 2, 3 or 4m 150mm diameter hose type arms with internal support structure. The unit has a 2.2kW fanset and is supplied with a 5m mains input cable. ProtectoAutoclenz Wall Twin unit weighs 165kg.
Product Specificaction
| Brand | Extractability |
|---|---|
| Length | 4M |
| Voltage | 415 |
| Power | 2.2kW |
| Arm Diameter (MM) | 150 |
| Spare Parts | |
| Filters | |
| Volume Flow | 3500m³ / Hr |
| Extraction point | 2 |
| Cleanable | Yes – Automatic |
| Filter Efficiency | W3 |
| Dimensions | 665mm x 981mm x 1625mm |
| Weight | 165kg |
| Noise Level | 72 dB (A) |
| IP Rating / ISO Class | IP54 / F |
| Application | Grinding Steel, MIG, Plasma, TIG. Oxy/Ace |
